Aluminium Bar Circular Saw Machine CNC-150

Sawing range

mm

Round  80-160

Carbide circular saw blade

mm

φ500xφ50xt2.7

Spindle motor

Kw

Kw 15/18.5 (spindle servo)

Spindle speed

Rpm

500-300

Cut off feeding mode

AC servo motor+ball screw

Main clamp mode

Hydraulic horizontal and vertical clamping each

Saw blade debris removal device

Passive/active round wire brush

gear clearance compensation device

Magnetic powder brake

Feeding drive type

AC servo motor+ball screw

Feeding clamp mode

Hydraulic horizontal  clamping

Front cut-off length

mm

15-20（optional）

Remaining length of tai

mm

90+α（αNot enough cutting length of one workpiece）

Cutting length of single feeding

mm

10-700

Allowable placing length

mm

3000-6500

Hydraulic drive motor

Kw

2.2

Hydraulic oil capacity

L

100

Machine  weight

Kg

4500
